| Dimensions and weights | |
|---|---|
| Length approx. | 820 mm |
| Width/depth approx. | 300 mm |
| Height approx. | 430 mm |
| Weight approx. | 31 kg |
Description:
- The machine bed is made of torsion-resistant gray cast iron for smooth running and precision
- Riding and headstock made of sturdy gray cast iron
- Tailstock with stroke 50 mm as standard with the revolving center point
- Speed adjustment in 5 stages via V-belt
- Turning steel support is easily adjustable
- Headstock quill with bore for long machining workpieces
- Tip width of 450 mm can be extended to 1000 mm via optional bed extension
USP:
- Especially quiet and quiet run
- Five speeds adjustable
- Tip width 450 mm optionally expandable to 1000 mm
Technical Specs:
| Max. turning diameter | 254 mm |
| Speeds | 680, 1000, 1400, 2000, 2800 min¯¹ |
| Speed stages | 5 |
| Travel of tailstock sleeve | 50 mm |
| VPE | 1 |
| Electrical Data | |
|---|---|
| Supply voltage | 230 V |
| Mains frequency | 50 Hz |
Scope of Delivery:
Unit: pc(s).
Packaging unit: 1
- tailstock
- revolving center of gravity
Your Dynamic Snippet will be displayed here...
This message is displayed because youy did not provide both a filter and a template to use.
Specifications
| Brand | HolzStar |
